Description
Key Points:
| MRC Rated Capacity | 6000 lb |
| Voltage | Battery Power 12 VDC |
| Wire Rope Included | Steel °21/64 in x 45 ft | °8.3 mm x 14 m |
| Speed (f/m) / min | 4~24 ft / 1.2~7.3 m |
| Control Included | Wired Remote Control |
| Warranty | 1 Year |
Technical Specifications:
| MRC Rated Capacity | 6000 lb | Transmission / Reducer Type | 3-Stage Planetary |
| Number of Speeds | 1 Speed | Free Spooling Clutch Type | Sliding Ring Gear |
| Voltage | Battery Power 12 VDC | Gear Ratio | 210:1 |
| Speed (f/m) / min | 4~24 ft / 1.2~7.3 m | Electric Control Box | Reverse Solenoid Control Box |
| Control Voltage | 12 V | Accessories | Control and Installation Hardware |
| Control Included | Wired Remote Control | IEC Motor Protection | IP67 |
| Motor Model | DC Permanent Magnet Motor | Warranty | 1 Year |
| Motor AMP | 280 AMP | Fairlead | Included |
| Drum Brake | In-Drum Automatic Brake | Number of Layers | 4 |
| Wire Rope Included | Steel °21/64 in x 45 ft | °8.3 mm x 14 m | Drum DL Length | 124 mm |
| 1st Layer MRC Capacity | 6000 lbs | Drum BD Barrel Diameter | 64 mm |
| FCC Cert ID | 2ASYP-DW12K |
