Description
- Spindle thread size 1 1/4″-7 (industry standard)
- Motor comes with slip clutch that can be easily adjusted from outside the motor
- 4 adjustable leveling screws for drilling uneven surfaces
- Double insulated construction
- Water valve swivels 360 degrees
- Engineered for both vertical and horizontal drilling
- Light weight drill is easy to carry and lift for wall drilling
- Roller slide carriage provides smooth drilling with low friction
- Automatic Feeding System available
- One-year limited warranty
| POWER | 230V |
| RATED CURRENT | 15.8A |
| MAX OUTPUT | 6.4kw (8.6HP) |
| MAX BIT CAPACITY | 16″ |
| SPINDLE THREAD | 1-1/4″-7 |
| COLUMN THICKNESS | 2-5/16″ |
| STAND HEIGHT | 39-3/8″ |
| CARRIAGE TRAVEL | 24-3/8″ |
| ANCHOR BASE | 7.5″ W x 10″ L |
| CLUTCH TYPE | Slip |
| SPEED+L2 | 300/800/1400 RPM (No Load) |
| WEIGHT | 76 lbs. (34.5kg) |
