Description
Key Points:
| MRC Rated Capacity | 1500 lb |
| Voltage | Battery Power 12 VDC |
| Wire Rope Included | Steel °3/16 in x 25 ft | °4mm x 7.6m |
| Speed (f/m) / min | 4.9~10.4 ft / 1.5~3.2 m |
| Control Included | Wired Remote Control |
| Warranty | 1 Year |
Technical Specifications:
| MRC Rated Capacity | 1500 lb | Transmission / Reducer Type | 1-Stage Planetary |
| Number of Speeds | 1 Speed | Free Spooling Clutch Type | YES |
| Voltage | Battery Power 12 VDC | Gear Ratio | 153:1 |
| Speed (f/m) / min | 4.9~10.4 ft / 1.5~3.2 m | Electric Control Box | Reverse Solenoid Control Box |
| Control Voltage | 12 V | Accessories | Control and Installation Hardware |
| Control Included | Wired Remote Control | IEC Motor Protection | IP67 |
| Motor Model | DC Permanent Magnet Motor | Warranty | 1 Year |
| Motor AMP | 132 AMP | Fairlead | Included |
| Drum Brake | In-Drum Automatic Brake | Number of Layers | 4 |
| Wire Rope Included | Steel °3/16 in x 25 ft | °4mm x 7.6m | Drum DL Length | 100 mm |
| 1st Layer MRC Capacity | 1500 lb | Drum BD Barrel Diameter | 80 mm |
| FCC Cert ID | 2ASYP-DW12K |
